Driver configuration structure. More...
#include <hal_uart_lld.h>
Data Fields | |
| uartcb_t | txend1_cb |
| End of transmission buffer callback. | |
| uartcb_t | txend2_cb |
| Physical end of transmission callback. | |
| uartcb_t | rxend_cb |
| Receive buffer filled callback. | |
| uartccb_t | rxchar_cb |
Character received while out if the UART_RECEIVE state. | |
| uartecb_t | rxerr_cb |
| Receive error callback. | |
| uartcb_t | timeout_cb |
| Receiver timeout (idle) callback. | |
| uint32_t | speed |
| Bit rate. | |
| uint16_t | cr1 |
| Initialization value for the CR1 register. | |
| uint16_t | cr2 |
| Initialization value for the CR2 register. | |
| uint16_t | cr3 |
| Initialization value for the CR3 register. | |
| uarthcb_t | rxhalf_cb |
| Half-transfer receive buffer callback. | |
Detailed Description
Driver configuration structure.
- Note
- Implementations may extend this structure to contain more, architecture dependent, fields.
Definition at line 129 of file hal_uart_lld.h.
Field Documentation
◆ cr1
| uint16_t UARTConfig::cr1 |
Initialization value for the CR1 register.
Definition at line 162 of file hal_uart_lld.h.
Referenced by uart_lld_start().
◆ cr2
| uint16_t UARTConfig::cr2 |
Initialization value for the CR2 register.
Definition at line 166 of file hal_uart_lld.h.
Referenced by uart_lld_start().
◆ cr3
| uint16_t UARTConfig::cr3 |
Initialization value for the CR3 register.
Definition at line 170 of file hal_uart_lld.h.
◆ rxchar_cb
| uartccb_t UARTConfig::rxchar_cb |
Character received while out if the UART_RECEIVE state.
Definition at line 145 of file hal_uart_lld.h.
◆ rxend_cb
| uartcb_t UARTConfig::rxend_cb |
Receive buffer filled callback.
Definition at line 141 of file hal_uart_lld.h.
◆ rxerr_cb
| uartecb_t UARTConfig::rxerr_cb |
Receive error callback.
Definition at line 149 of file hal_uart_lld.h.
◆ rxhalf_cb
| uarthcb_t UARTConfig::rxhalf_cb |
Half-transfer receive buffer callback.
Definition at line 174 of file hal_uart_lld.h.
◆ speed
| uint32_t UARTConfig::speed |
◆ timeout_cb
| uartcb_t UARTConfig::timeout_cb |
Receiver timeout (idle) callback.
Definition at line 153 of file hal_uart_lld.h.
◆ txend1_cb
| uartcb_t UARTConfig::txend1_cb |
End of transmission buffer callback.
Definition at line 133 of file hal_uart_lld.h.
Referenced by UartTsChannel::start(), and UartDmaTsChannel::start().
◆ txend2_cb
| uartcb_t UARTConfig::txend2_cb |
Physical end of transmission callback.
Definition at line 137 of file hal_uart_lld.h.
The documentation for this struct was generated from the following file:
- config/boards/kinetis/OS/os/hal/ports/KINETIS/LLD/UARTv2/hal_uart_lld.h
