mazda_miata.cpp File Reference

Detailed Description

FORD_ESCORT_GT = 14 set engine_type 14 http://rusefi.com/wiki/index.php?title=Vehicle:Mazda_Protege_1993

MRE_MIATA_94_MAP = 20 MIATA_1996 = 21 set engine_type 21

Date
Apr 11, 2014
Author
Andrey Belomutskiy, (c) 2012-2020

Definition in file mazda_miata.cpp.

Functions

void common079721_2351 ()


Variables

static const uint8_t miataNA8_maf_advance_table [16][16]


Function Documentation

◆ common079721_2351()

void common079721_2351 ( )

Definition at line 74 of file mazda_miata.cpp.

74 {
75 engineConfiguration->cylindersCount = 4;
76 engineConfiguration->firingOrder = FO_1_3_4_2;
77
78 engineConfiguration->fuelPumpPin = Gpio::Unassigned; // fuel pump is not controlled by ECU on this engine
79
80 engineConfiguration->crankingInjectionMode = IM_SIMULTANEOUS;
81 // set injection_mode 2
82 engineConfiguration->injectionMode = IM_BATCH;
83
84 // Frankenstein analog input #1: adc1
85 // Frankenstein analog input #2: adc3
86 // Frankenstein analog input #3: adc13
87 // Frankenstein analog input #4: adc11
88 // todo: see https://docs.google.com/spreadsheet/ccc?key=0Arl1FeMZcfisdEdGdUlHdWh6cVBoSzFIbkxqa1QtZ3c
89 // Frankenstein analog input #5: adc
90 // Frankenstein analog input #6: adc
91 // Frankenstein analog input #7: adc
92 // Frankenstein analog input #8: adc
93 // Frankenstein analog input #9: adc
94 // Frankenstein analog input #10: adc
95 // Frankenstein analog input #11: adc
96 // Frankenstein analog input #12: adc
97 engineConfiguration->mafAdcChannel = EFI_ADC_1;
98 engineConfiguration->tps1_1AdcChannel = EFI_ADC_3;
99 engineConfiguration->clt.adcChannel = EFI_ADC_11;
100
101}
Gpio::Unassigned
@ Unassigned
engineConfiguration
static constexpr engine_configuration_s * engineConfiguration
Definition engine_configuration.h:79
engine_configuration_s::fuelPumpPin
output_pin_e fuelPumpPin
Definition engine_configuration_generated_structures_alphax-2chan.h:1836
engine_configuration_s::tps1_1AdcChannel
adc_channel_e tps1_1AdcChannel
Definition engine_configuration_generated_structures_alphax-2chan.h:1646
engine_configuration_s::clt
ThermistorConf clt
Definition engine_configuration_generated_structures_alphax-2chan.h:1230
engine_configuration_s::cylindersCount
uint32_t cylindersCount
Definition engine_configuration_generated_structures_alphax-2chan.h:1289
engine_configuration_s::crankingInjectionMode
injection_mode_e crankingInjectionMode
Definition engine_configuration_generated_structures_alphax-2chan.h:1333
engine_configuration_s::mafAdcChannel
adc_channel_e mafAdcChannel
Definition engine_configuration_generated_structures_alphax-2chan.h:1687
engine_configuration_s::firingOrder
firing_order_e firingOrder
Definition engine_configuration_generated_structures_alphax-2chan.h:1293
engine_configuration_s::injectionMode
injection_mode_e injectionMode
Definition engine_configuration_generated_structures_alphax-2chan.h:1338

Referenced by setFordEscortGt().

Here is the caller graph for this function:

Variable Documentation

◆ miataNA8_maf_advance_table

const uint8_t miataNA8_maf_advance_table[16][16]
static

Definition at line 23 of file mazda_miata.cpp.

23 { {/*0 engineLoad=1.200*//*0 800.0*/+4, /*1 1213.0*/+11, /*2 1626.0*/
24 +23, /*3 2040.0*/+25, /*4 2453.0*/+25, /*5 2866.0*/+25, /*6 3280.0*/+29, /*7 3693.0*/
25 +32, /*8 4106.0*/+35, /*9 4520.0*/+37, /*10 4933.0*/+36, /*11 5346.0*/+30, /*12 5760.0*/
26 +29, /*13 6173.0*/+29, /*14 6586.0*/+27, /*15 7000.0*/+28 }, {/*1 engineLoad=1.413*//*0 800.0*/
27 +4, /*1 1213.0*/+12, /*2 1626.0*/+23, /*3 2040.0*/+25, /*4 2453.0*/+25, /*5 2866.0*/+25, /*6 3280.0*/
28 +29, /*7 3693.0*/+33, /*8 4106.0*/+34, /*9 4520.0*/+37, /*10 4933.0*/+35, /*11 5346.0*/
29 +30, /*12 5760.0*/+28, /*13 6173.0*/+28, /*14 6586.0*/+27, /*15 7000.0*/+27 }, {/*2 engineLoad=1.626*//*0 800.0*/
30 +4, /*1 1213.0*/+12, /*2 1626.0*/+23, /*3 2040.0*/+25, /*4 2453.0*/+25, /*5 2866.0*/+25, /*6 3280.0*/
31 +29, /*7 3693.0*/+33, /*8 4106.0*/+34, /*9 4520.0*/+37, /*10 4933.0*/+35, /*11 5346.0*/
32 +30, /*12 5760.0*/+29, /*13 6173.0*/+28, /*14 6586.0*/+27, /*15 7000.0*/+26 }, {/*3 engineLoad=1.839*//*0 800.0*/
33 +4, /*1 1213.0*/+12, /*2 1626.0*/+23, /*3 2040.0*/+25, /*4 2453.0*/+25, /*5 2866.0*/+25, /*6 3280.0*/
34 +29, /*7 3693.0*/+33, /*8 4106.0*/+34, /*9 4520.0*/+36, /*10 4933.0*/+36, /*11 5346.0*/
35 +30, /*12 5760.0*/+28, /*13 6173.0*/+28, /*14 6586.0*/+27, /*15 7000.0*/+26 }, {/*4 engineLoad=2.053*//*0 800.0*/
36 +4, /*1 1213.0*/+11, /*2 1626.0*/+23, /*3 2040.0*/+25, /*4 2453.0*/+25, /*5 2866.0*/+25, /*6 3280.0*/
37 +29, /*7 3693.0*/+32, /*8 4106.0*/+34, /*9 4520.0*/+37, /*10 4933.0*/+35, /*11 5346.0*/
38 +29, /*12 5760.0*/+28, /*13 6173.0*/+27, /*14 6586.0*/+28, /*15 7000.0*/+27 }, {/*5 engineLoad=2.266*//*0 800.0*/
39 +4, /*1 1213.0*/+11, /*2 1626.0*/+23, /*3 2040.0*/+25, /*4 2453.0*/+25, /*5 2866.0*/+25, /*6 3280.0*/
40 +29, /*7 3693.0*/+33, /*8 4106.0*/+34, /*9 4520.0*/+37, /*10 4933.0*/+35, /*11 5346.0*/
41 +31, /*12 5760.0*/+28, /*13 6173.0*/+28, /*14 6586.0*/+27, /*15 7000.0*/+26 }, {/*6 engineLoad=2.479*//*0 800.0*/
42 +4, /*1 1213.0*/+12, /*2 1626.0*/+23, /*3 2040.0*/+25, /*4 2453.0*/+25, /*5 2866.0*/+25, /*6 3280.0*/
43 +29, /*7 3693.0*/+33, /*8 4106.0*/+34, /*9 4520.0*/+36, /*10 4933.0*/+36, /*11 5346.0*/
44 +31, /*12 5760.0*/+28, /*13 6173.0*/+28, /*14 6586.0*/+27, /*15 7000.0*/+27 }, {/*7 engineLoad=2.693*//*0 800.0*/
45 +4, /*1 1213.0*/+12, /*2 1626.0*/+23, /*3 2040.0*/+25, /*4 2453.0*/+25, /*5 2866.0*/+26, /*6 3280.0*/
46 +30, /*7 3693.0*/+33, /*8 4106.0*/+34, /*9 4520.0*/+37, /*10 4933.0*/+36, /*11 5346.0*/
47 +30, /*12 5760.0*/+28, /*13 6173.0*/+29, /*14 6586.0*/+27, /*15 7000.0*/+28 }, {/*8 engineLoad=2.906*//*0 800.0*/
48 +4, /*1 1213.0*/+12, /*2 1626.0*/+23, /*3 2040.0*/+25, /*4 2453.0*/+25, /*5 2866.0*/+25, /*6 3280.0*/
49 +29, /*7 3693.0*/+33, /*8 4106.0*/+34, /*9 4520.0*/+37, /*10 4933.0*/+36, /*11 5346.0*/
50 +29, /*12 5760.0*/+28, /*13 6173.0*/+28, /*14 6586.0*/+26, /*15 7000.0*/+28 }, {/*9 engineLoad=3.119997*//*0 800.0*/
51 +4, /*1 1213.0*/+11, /*2 1626.0*/+23, /*3 2040.0*/+25, /*4 2453.0*/+25, /*5 2866.0*/+26, /*6 3280.0*/
52 +30, /*7 3693.0*/+33, /*8 4106.0*/+34, /*9 4520.0*/+38, /*10 4933.0*/+35, /*11 5346.0*/
53 +29, /*12 5760.0*/+29, /*13 6173.0*/+28, /*14 6586.0*/+27, /*15 7000.0*/+29 }, {/*10 engineLoad=3.33333*//*0 800.0*/
54 +4, /*1 1213.0*/+12, /*2 1626.0*/+23, /*3 2040.0*/+25, /*4 2453.0*/+25, /*5 2866.0*/+26, /*6 3280.0*/
55 +29, /*7 3693.0*/+33, /*8 4106.0*/+34, /*9 4520.0*/+37, /*10 4933.0*/+36, /*11 5346.0*/
56 +30, /*12 5760.0*/+29, /*13 6173.0*/+28, /*14 6586.0*/+27, /*15 7000.0*/+27 }, {/*11 engineLoad=3.546663*//*0 800.0*/
57 +4, /*1 1213.0*/+12, /*2 1626.0*/+23, /*3 2040.0*/+25, /*4 2453.0*/+25, /*5 2866.0*/+25, /*6 3280.0*/
58 +29, /*7 3693.0*/+32, /*8 4106.0*/+34, /*9 4520.0*/+38, /*10 4933.0*/+35, /*11 5346.0*/
59 +31, /*12 5760.0*/+28, /*13 6173.0*/+28, /*14 6586.0*/+27, /*15 7000.0*/+27 }, {/*12 engineLoad=3.759996*//*0 800.0*/
60 +4, /*1 1213.0*/+12, /*2 1626.0*/+23, /*3 2040.0*/+25, /*4 2453.0*/+25, /*5 2866.0*/+25, /*6 3280.0*/
61 +30, /*7 3693.0*/+33, /*8 4106.0*/+34, /*9 4520.0*/+37, /*10 4933.0*/+35, /*11 5346.0*/
62 +30, /*12 5760.0*/+28, /*13 6173.0*/+28, /*14 6586.0*/+27, /*15 7000.0*/+26 }, {/*13 engineLoad=3.973329*//*0 800.0*/
63 +4, /*1 1213.0*/+11, /*2 1626.0*/+23, /*3 2040.0*/+25, /*4 2453.0*/+25, /*5 2866.0*/+25, /*6 3280.0*/
64 +29, /*7 3693.0*/+33, /*8 4106.0*/+34, /*9 4520.0*/+37, /*10 4933.0*/+36, /*11 5346.0*/
65 +30, /*12 5760.0*/+28, /*13 6173.0*/+28, /*14 6586.0*/+27, /*15 7000.0*/+27 }, {/*14 engineLoad=4.186662*//*0 800.0*/
66 +4, /*1 1213.0*/+11, /*2 1626.0*/+23, /*3 2040.0*/+25, /*4 2453.0*/+25, /*5 2866.0*/+25, /*6 3280.0*/
67 +29, /*7 3693.0*/+33, /*8 4106.0*/+34, /*9 4520.0*/+36, /*10 4933.0*/+35, /*11 5346.0*/
68 +30, /*12 5760.0*/+28, /*13 6173.0*/+28, /*14 6586.0*/+27, /*15 7000.0*/+26 }, {/*15 engineLoad=4.399*//*0 800.0*/
69 +4, /*1 1213.0*/+12, /*2 1626.0*/+24, /*3 2040.0*/+25, /*4 2453.0*/+25, /*5 2866.0*/+25, /*6 3280.0*/
70 +29, /*7 3693.0*/+33, /*8 4106.0*/+36, /*9 4520.0*/+37, /*10 4933.0*/+36, /*11 5346.0*/
71 +29, /*12 5760.0*/+28, /*13 6173.0*/+28, /*14 6586.0*/+27, /*15 7000.0*/+27 } };

Go to the source code of this file.
